Diamond Saw Blade Induction Heater Brazing Machine 25KW High Frequency 200-1200A

Contact Now
Guang Yuan Technology (HK) Electronics Co., Limited
Visit Website
City:dongguan
Province/State:guangdong
Country/Region:china
Contact Person:MsCindy Yang
Contact Now

Diamond Saw Blade Induction Heater Brazing Machine 25KW High Frequency 200-1200A

Ask Latest Price
Video Channel
Brand Name :GY
Model Number :GY-25A
Certification :CE, FCC, ROHS, SGS
Place of Origin :CN
MOQ :1PC
Price :Negotiate
Payment Terms :T/T
Supply Ability :500PC PER MONTH
Delivery Time :2-3 WORKING DAYS AFTER RECEIVED THE PAYMENT
Packaging Details :PLY-WOODEN BOX PACKING
Heating principle :magnetic field induction heating
Application :Diamond Saw Blade Welding
more
Contact Now

Add to Cart

Find Similar Videos
CE, ROHS Approved High Frequency Induction Heating Equipment Melting Gold 00:17
CE, ROHS Approved High Frequency Induction Heating Equipment Melting Gold
80KHZ 25KW IGBT Control Portable Induction Heater For Screw 00:19
80KHZ 25KW IGBT Control Portable Induction Heater For Screw
FCC 50KHZ IGBT Audio Induction Quenching Machine For Shaft Hardening 00:33
FCC 50KHZ IGBT Audio Induction Quenching Machine For Shaft Hardening
30KW Induction Soldering  Equipment, hot fit machine, Magnetic field induction heating 00:15
30KW Induction Soldering Equipment, hot fit machine, Magnetic field induction heating
35KVA High Frequency Induction Heating Equipment For Hardening / Forging Furnace 00:14
35KVA High Frequency Induction Heating Equipment For Hardening / Forging Furnace
80KHZ IGBT Induction Heating Machine For Bolt Forging 00:10
80KHZ IGBT Induction Heating Machine For Bolt Forging
IGBT Surface Quenching 60KW 80KHZ Induction Heating Equipment/Device 00:27
IGBT Surface Quenching 60KW 80KHZ Induction Heating Equipment/Device
Online Wire - Steel Annealing Industrial Induction Heater , Induction Heat Treatment 70KVA 00:16
Online Wire - Steel Annealing Industrial Induction Heater , Induction Heat Treatment 70KVA
High Frequency 30-80khz Induction Heating Device 100KW DSP Full Digit 00:20
High Frequency 30-80khz Induction Heating Device 100KW DSP Full Digit
Ceramic conveyor belt for induction online forging, annealing feeder equipment 00:38
Ceramic conveyor belt for induction online forging, annealing feeder equipment
View Product Description

Technical Parameter :

Model GY-25A (Three phase)
work power 340V-430V
input current 25A
Fluctuating output power 25KW
fluctuating frequency 30-80KHZ
output current 200-1200A
the flow rate of cooling water 0.06-0.12Mpa 7.5L/Min
water temperature protection point 40C
product size 570x230x510mm
net weight 31kg

Application of Induction Heating Equipment

1, Heating (hot forging, hot fitting and smelting):

1) Hot forging aims to fabricate the work pieces of certain temperature (different materials require different temperatures) into other shapes through forging press with the help of punch press, forging machine or other equipments, for instances, hot extrusion of watch case, watch flan, handle, mold accessory, kitchen and table ware, art ware, standard part, fastener, fabricated mechanical part, bronze lock, rivet, steel pin and pin.

2) Hot fitting refers to the connection of different metals or metals with nonmetals through the heating based on the principle of hot expansion or hot smelting, for instances, embedded welding of copper core of computer radiator with aluminum sheet and speaker web, compound of steel and plastic tube, sealing of aluminum foil (tooth paste peel), motor rotor and sealing of tubular electric heating element.

3) Smelting mainly aims to melt the metal into liquid by using the high temperature, which is mainly applicable to the smelting of iron, steel, copper, aluminum, zinc as well as various noble metals.

2, Heat Treatment (surface quench):

It is mainly aims to change the rigidity of the metal materials through the heat treatment to work pieces. Detail applications are stated as follows:

1) Quench for various hardware and tools, such as plier, wrench, hammer, ax, screwing tools and shear (orchard shear).

2) Quench for various automobile and motorcycle fittings, such as crankshaft, connecting rod, piston pin, chain wheel, aluminum wheel, valve, rock arm shaft, semi drive shaft, small shaft and fork.

3) Various electric tools, such as gear and axes.

4) Quench for machine tools, such as lathe deck and guide rail.

5) Quench for various hardware metal parts and machined parts, such as shaft, gear (chain wheel), cam, chuck and clamp etc.

6) Quench for hardware molds, such as small-size mold, mold accessory and inner hole of mold.

3, Welding (braze welding, silver soldering and brazing)

It mainly aims to melt the solder by heating it to a certain temperature for the purpose of connecting two types of metals of the same material or different materials.

1) Welding of various hardware cutting tools, such as diamond tool, abrasive tool, drilling tool, alloy saw blade, hard alloy cutter, milling cutter, reamer, planning tool and solid center bit.

2) Welding of various hardware mechanical gadget: Silver soldering and brazing of metals of the same variety or different varieties, such as hardware toilet and kitchen products, refrigerating copper fitting, lamp decoration fitting, precision mold fitting, hardware handle, eggbeater, alloy steel and steel, steel and copper as well as copper and copper.

3) Compound pot bottom welding is mainly applicable to the braze welding of circular, square as well as other irregular plain pot bottom. It is also applicable to plain braze welding of other metals.

4) Welding of heating disc of electric hot-water kettle mainly refers to the braze welding of stainless steel flat base, aluminum sheet and tubular electric heating elements of various forms.

4, Annealing (tempering and modulation):

1) Annealing of various stainless steel products, such as stainless steel basin, annealed and extruded can, annealed folded edge, annealed sink, stainless steel tube, tableware and cup.

2) Annealing of various other metal work pieces, such as golf ball head, cue, brass lock, hardware copper fitting, kitchen knife handle, blade, aluminum pan, aluminum pail, aluminum radiator and various aluminum products.

Diamond Saw Blade Induction Heater Brazing Machine 25KW High Frequency 200-1200A
